special-workholdingGMT SPECIAL WORKHOLDING

CUSTOM BUILT CHUCKS

GMT Chucks for special applications. Guindy Machine Tools provides solutions for all workholding problems, whether cylindrical or non-cylindrical, as a result of years of experience. These chucks can be designed to suit your component requirements. We have chucks designed to grip all kinds of irregular shaped components, such as bonnets, knuckles, valve bodies and many other such components. The list of applications of the specials product range is long. CALL +91 87544 83577 or mail us at esales@gmt.co.in

Power Operated Eccentric Compensating Chuck (PE)

The Eccentric Compensating Chuck is for machining forgings and black bars between centres. These chucks are essentially meant for applications where the component is located between centres. One side of the component is mounted on the centre on the chuck body and one on the tailstock of the machine. more…

Eccentric Compensating Chuck with Retractable Jaw (PER)

The Eccentric Compensating Chuck with two / three retractable jaws permits machining of shafts, bars, forgings in full length in a single set up, centre to centre. The jaws grips the component in the first operation. Next, in the finishing operation, the jaws retracts and the component is driven by the face driver for machining the outside diameter. more…

Power Operated Pneumatic Front End Chuck (PF)

GMT Power Operated Pneumatic Front End Chucks utilizes the spindle bore for bar/pipe work, in full,. The actuating cylinder is built into the chuck. Consequently,there is no actuating cylinder mounted at the rear, with the  necessary draw bar connections. Above all, the stationary air distribution system is mounted separately on the chuck. more…

Quick Change Jaw Chuck (PHQC)

The GMT  Quick Change Jaw Chuck reduces the change over time of jaws for different components and is suitable for machining small and medium size batches. Also, the base jaws, fitted with top hard or soft jaws can be pre-turned or ground to suit different components and kept ready. Whenever the component changes, you can change the corresponding base jaw with top jaws very quickly. more…

Universal Ball Lock Chucks (UBLC)

Ball Lock Chucks have certain distinctive advantages over wedge and lever type chucks. Sliding and swivel of the base jaws achieves jaw movement of ample proportions. Therefore, there is less wear, less bearing pressure and less stress in the jaws. Apart from the radial clamping forces, these chucks provide an axial force to pull the component against the butting face. There is a positive pull back action against jaw face after clamping, due to spherical movement, and positive sealing to prevent entry of chips. more…

Power Operated Hand Indexing Chuck (POHI)

GMT make Power Operated Hand Indexing Chuck is ideal for machining valves, bonnet, etc. for components with intersecting axes. Consequently, multiple machining operations can be performed in a single setup.This reduces the production time. The component clamps between the jaws. Finally, after the machining operation is over, lifting the index lever causes the component to index to the next position with the jaws. more…

Power Operated Power Indexing Chucks (POPI)

GMT Power Operated Power Indexing Chucks are primarily for machining valves, bonnet, universal joints and spiders. Furthermore, they have integral hydraulic cylinders to perform clamping, de-clamping, indexing and locking of index drum. The oil is fed to the different cylinders through a pipe bundle running through the spindle bore. more…

Twist Finger Chuck (PW)

As a result of finger action, the Twist Finger Chuck is ideal for clamping the component on the face with centralized location, where clamping on OD/ID facilities are not possible. Typical examples are brake drums and automobile hub wheels. more…

Diaphragm Chuck (DC)

GMT Diaphragm Chuck (DC)Diaphragm Chucks are ideal for thin-walled components. Furthermore, these chucks are ideal for light, accurate turning, fine boring, facing and grinding operations. As a result, diaphragm chuck improves accuracy. It maintains concentricity during precision machining operations. more…

Collet Chuck (CC)

The GMT Collet Chuck is suitable for machining components of various geometric shapes, like round, square and hexagonal with finished gripping areas at high speed. Also, this chuck is interchangeable with the standard GMT power chuck and runs on CNC lathes too.. The actuation of the chuck is by a hydraulic cylinder. Furthermore, it has a compact design, and the permissible run out accuracy is as per DIN 6386. It is available in four sizes: 26mm, 42mm, 60mm and 80mm. Also, we can design and produce special application collet chucks customized to your requirement. more…

Grip Down / Pull Back Chuck (GDC)

The Grip Down Chuck is ideal for the finishing operation. Consequently, the Radial pull back function of the chuck ensures Positive resting of the component after clamping, parallelism, high gripping force and repeatability. This chuck is suitable for auto components. more…

Expanding Mandrel

A typical application of the GMT Expanding Mandrel is clamping of components on internal diameter, to machine in a single setup. Also, it maintains concentricity and  even at high clamping force. more…

Other Specials

Besides the above mentioned special workholding, we also manufacture Crank Shaft Machining Chuck, Friction Welding Chucks, Knuckle Fixture Chuck, 1300mm Ø PS Chucks, Facing Heads, Steady Rest Bevel Gear Chuck, Dust Proof Chuck.

Finally, please visit us at https://gmtmachinetools.blogspot.com – a new blog dedicated to all GMT customers…interact with our technical experts
